GGG .308 WIN DESIGN GPX15
Back
Technical specification
Caliber | .308 WIN | |
Bullet type | type | HPBT |
|---|---|---|
Bullet weight | g gr | 11,34 175 |
Total length | mm | 71,12 (-0,40) |
Bullet extraction | N | ≥50 |
Bullet material | Jacket – CuZn5; Core – lead antimony (3%) | |
Case material | CuZn30 | |
Case length | mm | 51,18 (-0,38) |
Propellant | type | Dvikomponentis |
Total weight | g | 25,58±1,00 |
Primer | type | BOXER |
Ballistic Properties
PARAMETER | BULLET MEAN VELOCITY V0, m/s |
|---|---|
Bullet mean velocity, m/s barrel length 600 mm, twist 11“ | 810 ± 7 |
Velocity maximum standard deviation | 7,2 |
PARAMETERS | RANGE | |||||
|---|---|---|---|---|---|---|
0 | 100 | 200 | 300 | 400 | 500 | |
Velocity (m/s) | 810 | 750 | 690 | 640 | 585 | 535 |
Bullet path (cm) | - | 0 | -17 | -55 | -118 | -209 |
Energy (J) | 3720 | 3185 | 2715 | 2300 | 1935 | 1620 |
Ballistic coefficient | 0.496 | |||||
